DEUTZ BF6L914C Engine Load Haul Dump Machine , underground lhd mining equipment KSQ RL -3

Name: DEUTZ BF6L914C Engine Load Haul Dump Machine underground lhd mining equipment KSQ RL 3
Brand: ROXMECH
Price: 1 USD

Wholesale DEUTZ BF6L914C Engine Load Haul Dump Machine , underground lhd mining equipment KSQ RL -3 from china suppliers

Brand Name : ROXMECH

Model Number : RL-3 Load Haul Dump Machine/ScoopTram

Certification : CE, ISO9001

Place of Origin : China

MOQ : 1

Payment Terms : T/T, L/C, D/A, D/P, Western Union

Delivery Time : 2 Months

Packaging Details : Suitable for Long Transportation

Color : Orange/Yellow/White

Application : Tunnel/Underground Mining

Bucket Capacity : 3 cubic meter

Engine : DEUTZ BF6L914C

Payload : 6000 kg

Deadweight : 17000 kg

Price : negotiation

Contact Now

DEUTZ BF6L914C Engine Load Haul Dump Machine , underground lhd mining equipment KSQ RL -3

Competitive Advantage:

1. CE, ISO9001 Certified
2. Very competitive pricing
3. Professinal Service Team
4. Fast feedback about all questions from clients

5. Design based on your specific requirements

Applications:
• Underground Mining
• Hydropower Tunneling
• Roadway/Railway Tunneling
• Can be utilized as a multi-role equipment with various attachments (i.e. shotcrete robot arm)

Operation Advantage:

The RL-3 Load-Haul-Dump Machine is ideal for medium to large scale rock excavation operations. The RL-3 maintains the simple yet very robust design tenets of what a mining equipment should be - it has high proven reliability, and straight-forward mechanical components that are easy to maintain.

Main Technical Configuration:

Model:	RL-3 Load Haum Dump Machine
1 Rated Bucket Capacity(SAE, heaped)	3.0 m3
2 Payload	6000 kg
3 Deadweight	17000 kg
4 Bucket
Maximum lift height	4615 ± 50 mm
Maximum dumping height	1810 ± 50 mm
Required dumping height clearance	1621 ± 50 mm
Dumping angle	40 o ± 2 o
5 Maximum tramming speed Laden forward/reverse, on a level roadway
1^st Gear	4.7 km/h
2nd Gear	9.5 km/h
3rd Gear	16.4 km/h
6 Gradeability	14% - Minimum speed of 3.5 km/h (based on good road conditions) 34% - Minimum speed of 2.5 km/h (based on good road conditions)
7 Engine
Model	DEUTZ BF6L914C
Design	Turbocharged, charge air cooler, air- cooled diesel engine
Max. power	144 kW/2500 rpm
Max. torque	700 Nm/1600 rpm
8 Torque converter	DANA R32420
9 Axles
Front Axle
Model	DANA 16D2149LCB
Design	Rigid planetary axles with no-spin differential gear
Rear Axle
Model	DANA 16D2149LCB
Design	Rigid planetary axles with no-spin differential gear
Swing angle	± 10o
10 Minimum Turning Radius	3600mm Inside, 6400mm Outside
11 Maximum Steering Angle	40o
12 Minimum Ground Clearance	≥280 mm
13 Size
Length(Bucket in haul position)	8868 mm
Width	2112 mm
Height of the Cab	2275 mm

Packaging & Shipping

By Truck:

Product Information

ROXMECH® Brand by KSQ Technologies (Beijing) Co. Ltd.
ROXMECH® Rock Excavation and Service/Support Equipment include:

Load Haul Dump Machines
RL-1 Load-Haul-Dump Machine
RL-2 Load-Haul-Dump Machine
RL-3 Load-Haul Dump Machine
RL-4 Load-Haul Dump Machine

Low Profile Dump Trucks
RT-12 Low Profile Dump Truck
RT-15 Low Profile Dump Truck
RT-20 Low Profile Dump Truck
MT30D Low Profile Dump Truck

Support Equipment
RS-3 Service Vehicle Series
MT30M Low Profile Transmixer

Processing Equipment
TT Series Vacuum Ceramic
Filtration System

Exhibition Activity

Bauma China 2016, in Shanghai
from Nov. 22-25, Booth number: W5.146
DEUTZ BF6L914C Engine Load Haul Dump Machine , underground lhd mining equipment KSQ RL -3

2016 MINExpo, Las Vegas, USA from Sep. 26-28
Booth Number: North 655
Much welcome all friends to visit us there!
